Hobbywing Xerun V10 Brushless Motor G4r (2-3s) 13.5t Sensored 1:10

Hobbywing Xerun V10 Brushless Motor G4r (2-3s) 17.5t Sensored 1:10

Hobbywing Xerun V10 Brushless Motor G4r (2-3s) 21.5t Sensored 1:10

HOBBYWING  is proud to present the newest rotor(5-12.3/12.5-U-T) for the V10 G3 motor series.

The characteristic of the titanium bonded rotor provides a milder, smoother pickup acceleration without losing its top speed. The rotor will aid drivers especially on lower grip surfaces and allow drivers to accelerate quicker out of tighter corners. The rotor has been extensively tested and race proven by Top Drivers on carpet and  low grip asphalt tracks around the world. Highly recommended for all HOBBYWING XR10 Pro users on their Modified motors.

This Hobbywing speedo is the perfect product to race stock with the same chances for everybody. The quality is insane and the speedo is working very smooth and powerful as well . The XeRun Justock XR10 will be the speedo of choice for the new FWD class at the ETS series and is also perfect for all other applications where people are looking for limited electronics with great features, maximum performance and a valuable pricing! For easy identification there will be laser engraved ETS logo on the speedo. The XR10 Justock comes with a pre-installed software which will be in use at the ETS (RPM limiter for even horsepower).

Hobbywing Xerun Xr10 Justock G3 Handout Spec Esc 60a, 2s-3 Lipo, Bec 3

The XR10 JUSTOCK G3S ESC offers even more setting options and finer adjustment to Your own driving style than the regular Justock G3 controller. Developed specifically for races and training rides, both a 0 timing and an RPM limit of up to 88,000RPM are of course available. So get ready for a fair and successful race. Another new feature is that the motor can rotate clockwise or counterclockwise thanks to the Justock G3S ESC. With the equally adjustable BEC voltage, there are countless possibilities for combining the controller with the other electronics of an RC car. Also there are numerous safety functions such as reverse polarity protection, which ideally prevents damage caused by the battery being plugged in incorrectly by accident.

The Xerun series from Hobbywing exclusively includes sensor-based brushless systems for professional racing use. The product range extends from 1/12 scale to 1/8 as well as from Modified to Stock. The excellent performance, high reliability and several other features meet the high requirements of top-level drivers in all respects.

Features:

• Even more available parameters than the normal Justock G3 controller (smart fan, freewheeling, initial throttle force)
• Refined parameter options
• RPM limit of 10000RPM up to 88000RPM in 1000 steps (instead of only 25000 or 33500)
• Perfectly suited for competition thanks to the RPM-Limit and 0-Timing options
• Motor direction of rotation free choosable (CW or CCW)
• Adjustable BEC Voltage (6V or 7,4V)
• Robust aluminum housing for ideal heat dissipation
• Built-in capacitors
• Firmware upgrades possible to always be up to date
• Various protective functions:
  • Polarity reversal
  • Overheating
  • Undervoltage shutdown
  • Fail-safe
  • Motor lock-up

Technical Specifications:

Optional Accessories:

HW30502001 LCD Programming Box G2
HW30502002 LCD Programming Box Pro
HW30850400 OTA Programmer

Product information "Hobbywing Xerun XR10 Pro Brushless ESC Black 160A, 2-3s LiPo"

All the products in this series are sensored brushless power systems for professional races range from 1/12th scale to 1/8th scale, from Modified to Stock. Their excellent performance, reliable structure design and others definitely can meet top-level races strict requirements against products performance and quality.
The XR10 Pro is a real and maybe THE ESC for 1/10 competition use. Doesn`t matter if On-Road touring cars or Off-Road Buggies, the feeling and power with this ESC is amazing. With outstanding features like Data-logging Function, adjustable Throttle and Brake frequencies, powerful BEC and a max. const. current of 160A.

High Power Output
Continuous current of 160A and peak current of up to 1200A guarantees a stable and high power output during competitions.

Special Design for Top Racing
Reliable hardware combined with intelligent software (containing 10 common select-to-use profiles) creates an ideal power solution to 1/10th scale top touring car, Pan car and buggy racing.

Programming / Upgrading / Data reading wirelessly
With Hobbywings WiFi Express module and iPhone or an Android phone (with the HOBBYWING WiFi Link software installed), the user can remotely program parameters, upgrade firmware and check relevant data of the ESC without leaving the control stand.

Adjustable Throttle & Brake PWM Frequencies
Independent and adjustable throttle & brake PWM frequencies guarantee precise and accurate throttle and brake control for all classes of competitions (esp. the Stock class).

Efficient Heat Dissipating System
The aluminum casing and reticular heat sink combined with the HOBBYWING patented copper heat-conductive plates which are attached to the MOSFET board allows the internal heat to be quickly transferred to the heat sink for dissipation. With the high-performing detachable cooling fan, a highly reliable heat transfer system for maximum cooling is accomplished.

High current/voltage BEC
The built-in switch mode BEC with a maximum output of 4A and voltage adjustable between 6V and 7.4V allows the user to use various high voltage servos.

Separate Programming/Fan Port
The separate PRG/FAN port on the ESC can power an external fan for maximize cooling performance or connect the ESC to a LCD program box or WiFi module for ESC programming.

Advanced and Secure Electronic Switch
The XR10 Pro ESC features an electronic switch with a lifespan of over 50000 on/off cycles, housed in a completely waterproof, dust-proof and shock-resistant design.

Innovative data-logging Function
This ESC features the data-logging function which can record the maximum ESC/motor temperature, RPM and etc. in real time and allows the user to analyze the recorded data via a the LCD program box or WiFi module after each use.


Specifications

• Type
  • Scale: 1/10th
  • Brushed/Brushless: BL
  • Sensored/Sensorless: SD
  • Waterproof: No
• Specifications
  • Cont./Peak Current: 160A/1200A
  • Input: 2-3S LiPo / 4-9 Cell NiMH
  • BEC Output: Swich Mode: 6V / 7.4V max. 4A
• Wires & Connectors
  • Input Wires: Black-12AWG-200mm*2
  • Output Wires: Black-12AWG-200mm*3
  • Input Connectors: No
  • Output Connecotors: No
• Fan
  • Size: 25.0x25.0x10.0mm
  • Voltage Range: 5-7.4V
  • Powered by: Powered by BEC
• ESC Programing via
  • LCD Program Box: Supported
  • WiFi Module: Supported
  • Program Port: Separate Program Port
• Size & Weight
  • Size: 37.5x30.9x31.6mm(w/Fan & Fan Shroud)
  • Weight: 95g(w/ Wires)
• Applications
  • Motors: SL BL Motors / SD BL Motors
  • Vehicles: 1/10th Touring Car & Buggy & Drift Car & F1; 1/8th,1/10th Rock Crawler
  • KV Rating/T Count:
    • 2S LiPo/6S NiMH: (Touring Car) T=3.5T, (Buggy) T=4.5T.
    • 3S LiPo/9S NiMH: (Touring Car) T=6.5T, (Buggy) T=8.5T.

Product Comparison

Hobbywing Xerun Xr10 Pro Elite G2s

Hobbywing Xerun XR10 Pro G2S

Hobbywing Xerun XR10 Pro G3 Brushless ESC 160A, 2s LiPo

The Hobbywing XeRun XR10 Pro G3 sets new standards for competition ESCs and raises the performance level with many innovative features. Compared to its predecessor, the XR10 Pro G2S, the ESC is now equipped with a frameless and improved fan. Additionally, the optimized LCG design has reduced the height by 2 mm, leading to a lower center of gravity and improved vehicle balance. Moreover, the XR10 Pro G3 features an integrated data logging module that can store up to 19 data sets of 20 minutes each, eliminating the need for a constant connection to the OTA Bluetooth module.

In addition to the integrated data logging, the G3 comes with many interesting new features! The freewheeling function ensures more efficient cooling by noticeably lowering the operating temperature compared to its predecessor. The new Disc Brake Mode allows extremely precise and linear brake force control, making braking consistent and controllable across all speeds. With over 44 programmable parameters and two adjustment levels, the settings can now be better tailored to any situation.

Features:

• Integrated data logging (OTA/LCD required for analysis)
• Optimized temperature control
• Disc Brake Mode for precise brake control
• 44+ parameters
• Softening 2.0
• LCG design and optimized wiring
• Built-in reverse polarity protection
• Optimized for modified competitions

Technical Data:

Accessories (optional):

HW30502001 LCD programming box
HW30850400 OTA programming module

•  Do you have any questions concerning this product?
•  Further products by Hobbywing

Hobbywing Xerun XR10 Pro G3X Brushless ESC 160A, 2s LiPo

The Hobbywing XeRun XR10 Pro G3X sets new standards for competition ESCs and raises the performance level with many innovative features. Compared to its predecessor, the XR10 Pro G2S, the ESC is now equipped with a frameless and improved fan. Additionally, the optimized LCG design has reduced the height by 2 mm, leading to a lower center of gravity and improved vehicle balance. Moreover, the XR10 Pro G3X features an integrated data logging module that can store up to 19 data sets of 20 minutes each, eliminating the need for a constant connection to the OTA Bluetooth module.

In addition to the integrated data logging, the G3X comes with many interesting new features! The freewheeling function ensures more efficient cooling by noticeably lowering the operating temperature compared to its predecessor. The new Disc Brake Mode allows extremely precise and linear brake force control, making braking consistent and controllable across all speeds. With over 44 programmable parameters and two adjustment levels, the settings can now be better tailored to any situation.

Compared to the G3 standard version in black, the G3X delivers a more aggressive power output and comes standard with 12AWG wires and no reverse polarity protection.

Features:

• Integrated data logging (OTA/LCD required for analysis)
• Optimized temperature control
• Disc Brake Mode for precise brake control
• 44+ parameters
• Softening 2.0
• LCG design and optimized wiring
• Optimized for stock competitions

Technical Data:

Accessories (optional):

HW30502001 LCD programming box
HW30850400 OTA programming module

Hobbywing XeRun XR10 PRO STOCK SPEC 1S Sensored Brushless ESC (Black) 80A

The second generation XR10 Stock Spec was developed specifically for 1/10 Touring Car and Buggy STOCK classes. Reliable hardware combined with great software are ideal conditions for tough racing uses. 32 different parameters allow You to individually adapt the controller to the current racing conditions and Your very own driving style. Anyone who loves evaluating their race records will not be disappointed by the extensive data logging function. This allows the driver to record information such as the different temperatures of the controller and motor and other values in real time while driving - simply to check on everything later. And if something should happen, the XR10 Stock Spec G2 ESC is equipped with extensive safety features to keep the driving fun for as long as possible.
Features:

• Over 30 adjustable parameters
• 3 instantly selectable profiles for 1/10 car racing
• Super BEC switchable between 6V and 7.4V at 5A
• Adjustable turbo timing and boost timing
• Separate PRG/FAN connection for connecting an external fan or a programming box/OTA programming module
• Variable frequency regulation of the PWM & braking frequencies for more precise driving and braking
• Real-time data recording to record the maximum controller and motor temperature, motor speed and other values
• Various protective functions:
  • Overheating protection
  • Undervoltage shutdown
  • Fail safe
  • Reverse polarity protection*

• HW30502002 LCD Program Box Pro
• HW30850400 OTA Program Module

• Xerun XR10 Stock Spec G2-Regler
• Manual (English)
• Sticker & mounting set
• Fan

Hobbywing Xerun Xr10 Stock Spec Brushless Esc 100a, 2s Lipo, Bec 5a

Hobbywing XERUN XR8 Pro G2S 200A 1/8 Buggy/On Road CompetitionHW30113304

Hobbywing Xerun Xr8 Pro G3 Brushless Esc 200a, 2-4s Lipo, Bec 6a
