What comes in the box?
All editions come with

• XR10 PRO ESC G2 w/ a cooling fan
• 13AWG wires for flexible layout / lightweight
• (2) Input wires & (3) Output wires
• (2) x cooling fan (comes with one back-up fan)
• Dual capacitors
• Decals
• Bonus parts: heat tubes, double tape, nylon cable zap traps

Edition package (P/N | SKU)	Electric  Blue (30112612)
Color
Wires	13 AWG (racing)
Secondary Extended power switch	Option (Not included)

Features:

• Upgraded 32-bit M4 microprocessors with more powerful processing capability guarantee stable control and rapid response. (Industry's highest 32-bit microprocessor, increased processing speed by X4)
• Peak current up to 1200A. (this is not a typo)
• Built-in switch mode BEC with a maximum output of 10A and voltage adjustable from 5V to 7.4V (step: 0.1V) for usage with servos & other devices require different voltages.
• Variable frequency regulation of PWM & brake frequencies allows users to precisely regulate the driving; braking forces (of the motors).
• Expanded range of the max. brake force brings in the active brake ranges from 101% to 150%.
• Softening function (HOBBYWING-initiated) for milder or wilder driving control and better driving efficiency.
• 10 select-to-use profiles applicable to all 1/10th RC car racing.
• Internal electronic key switch for long service life, high reliability; and the external switch port for connecting an external switch (included in the product box) is applicable to different situations.
• Separate PRG/FAN port is able to power an external fan to maximize cooling performance or connect an LCD program box or WiFi module to the ESC.
• With the New WIFI express module (purchase separately), users are able to program parameters, upgrade firmware and check relevant data during the event using either the iPhone or Android devices.
• Switchable motor direction (CCW/CW) for various chassis.
• Multiple protections come in standard
  • low-voltage cutoff protection
  • ESC and motor thermal protection
  • Fail-safe (throttle signal loss protection)
  • Reverse polarity protection*
• Data logging for recording the maximum ESC/motor temperature, motor speed/RPM, and others in real-time.
• Firmware upgrade via Hobbywing multifunction LCD program box or WiFi Express (item sold separately).

* The external standard cap pack will still be damaged if battery reversal occurs. For full protection, recommend using HOBBYWING SMT-MLCC capacitor banks (purchase separately)

Specifications

This Hobbywing speedo is the perfect product to race stock with the same chances for everybody. The quality is insane and the speedo is working very smooth and powerful as well . The XeRun Justock XR10 will be the speedo of choice for the new FWD class at the ETS series and is also perfect for all other applications where people are looking for limited electronics with great features, maximum performance and a valuable pricing! For easy identification there will be laser engraved ETS logo on the speedo. The XR10 Justock comes with a pre-installed software which will be in use at the ETS (RPM limiter for even horsepower).

Hobbywing Xerun Xr10 Justock G3 Handout Spec Esc 60a, 2s-3 Lipo, Bec 3

The XR10 JUSTOCK G3S ESC offers even more setting options and finer adjustment to Your own driving style than the regular Justock G3 controller. Developed specifically for races and training rides, both a 0 timing and an RPM limit of up to 88,000RPM are of course available. So get ready for a fair and successful race. Another new feature is that the motor can rotate clockwise or counterclockwise thanks to the Justock G3S ESC. With the equally adjustable BEC voltage, there are countless possibilities for combining the controller with the other electronics of an RC car. Also there are numerous safety functions such as reverse polarity protection, which ideally prevents damage caused by the battery being plugged in incorrectly by accident.

The Xerun series from Hobbywing exclusively includes sensor-based brushless systems for professional racing use. The product range extends from 1/12 scale to 1/8 as well as from Modified to Stock. The excellent performance, high reliability and several other features meet the high requirements of top-level drivers in all respects.

Features:

• Even more available parameters than the normal Justock G3 controller (smart fan, freewheeling, initial throttle force)
• Refined parameter options
• RPM limit of 10000RPM up to 88000RPM in 1000 steps (instead of only 25000 or 33500)
• Perfectly suited for competition thanks to the RPM-Limit and 0-Timing options
• Motor direction of rotation free choosable (CW or CCW)
• Adjustable BEC Voltage (6V or 7,4V)
• Robust aluminum housing for ideal heat dissipation
• Built-in capacitors
• Firmware upgrades possible to always be up to date
• Various protective functions:
  • Polarity reversal
  • Overheating
  • Undervoltage shutdown
  • Fail-safe
  • Motor lock-up

Technical Specifications:

Optional Accessories:

HW30502001 LCD Programming Box G2
HW30502002 LCD Programming Box Pro
HW30850400 OTA Programmer

Product information "Hobbywing Xerun XR10 Pro Brushless ESC Black 160A, 2-3s LiPo"

All the products in this series are sensored brushless power systems for professional races range from 1/12th scale to 1/8th scale, from Modified to Stock. Their excellent performance, reliable structure design and others definitely can meet top-level races strict requirements against products performance and quality.
The XR10 Pro is a real and maybe THE ESC for 1/10 competition use. Doesn`t matter if On-Road touring cars or Off-Road Buggies, the feeling and power with this ESC is amazing. With outstanding features like Data-logging Function, adjustable Throttle and Brake frequencies, powerful BEC and a max. const. current of 160A.

High Power Output
Continuous current of 160A and peak current of up to 1200A guarantees a stable and high power output during competitions.

Special Design for Top Racing
Reliable hardware combined with intelligent software (containing 10 common select-to-use profiles) creates an ideal power solution to 1/10th scale top touring car, Pan car and buggy racing.

Programming / Upgrading / Data reading wirelessly
With Hobbywings WiFi Express module and iPhone or an Android phone (with the HOBBYWING WiFi Link software installed), the user can remotely program parameters, upgrade firmware and check relevant data of the ESC without leaving the control stand.

Adjustable Throttle & Brake PWM Frequencies
Independent and adjustable throttle & brake PWM frequencies guarantee precise and accurate throttle and brake control for all classes of competitions (esp. the Stock class).

Efficient Heat Dissipating System
The aluminum casing and reticular heat sink combined with the HOBBYWING patented copper heat-conductive plates which are attached to the MOSFET board allows the internal heat to be quickly transferred to the heat sink for dissipation. With the high-performing detachable cooling fan, a highly reliable heat transfer system for maximum cooling is accomplished.

High current/voltage BEC
The built-in switch mode BEC with a maximum output of 4A and voltage adjustable between 6V and 7.4V allows the user to use various high voltage servos.

Separate Programming/Fan Port
The separate PRG/FAN port on the ESC can power an external fan for maximize cooling performance or connect the ESC to a LCD program box or WiFi module for ESC programming.

Advanced and Secure Electronic Switch
The XR10 Pro ESC features an electronic switch with a lifespan of over 50000 on/off cycles, housed in a completely waterproof, dust-proof and shock-resistant design.

Innovative data-logging Function
This ESC features the data-logging function which can record the maximum ESC/motor temperature, RPM and etc. in real time and allows the user to analyze the recorded data via a the LCD program box or WiFi module after each use.


Specifications

• Type
  • Scale: 1/10th
  • Brushed/Brushless: BL
  • Sensored/Sensorless: SD
  • Waterproof: No
• Specifications
  • Cont./Peak Current: 160A/1200A
  • Input: 2-3S LiPo / 4-9 Cell NiMH
  • BEC Output: Swich Mode: 6V / 7.4V max. 4A
• Wires & Connectors
  • Input Wires: Black-12AWG-200mm*2
  • Output Wires: Black-12AWG-200mm*3
  • Input Connectors: No
  • Output Connecotors: No
• Fan
  • Size: 25.0x25.0x10.0mm
  • Voltage Range: 5-7.4V
  • Powered by: Powered by BEC
• ESC Programing via
  • LCD Program Box: Supported
  • WiFi Module: Supported
  • Program Port: Separate Program Port
• Size & Weight
  • Size: 37.5x30.9x31.6mm(w/Fan & Fan Shroud)
  • Weight: 95g(w/ Wires)
• Applications
  • Motors: SL BL Motors / SD BL Motors
  • Vehicles: 1/10th Touring Car & Buggy & Drift Car & F1; 1/8th,1/10th Rock Crawler
  • KV Rating/T Count:
    • 2S LiPo/6S NiMH: (Touring Car) T=3.5T, (Buggy) T=4.5T.
    • 3S LiPo/9S NiMH: (Touring Car) T=6.5T, (Buggy) T=8.5T.

Product Comparison

Hobbywing XeRun XR10 PRO-1S V4 ESC 120A - 30112603


Special Design for 1/12th Scale Top Racing

Reliable hardware combined with great software (contains 5 common ready-to-use profiles)
creates an ideal power solution to1/12th scale top touring car racing.

Small Size & Light Weight

Height of 15.9mm (6mm shorter than the previous V3.1 1S ESC) saves space and makes the
installation convenient; weight of 35.6g (12g lighter than the previous V3.1 1S ESC)
provides more weight margin when adjusting the balance of the chassis.

Super BEC

Internal BEC features booster circuitry can output the current/voltage of up to 6A/6V and
power various servos without connecting any extra receiver battery.
Built-in Electronic Switch & Capacitor Module

Built-in Electronic Switch & Capacitor Module

The built-in electronic switch with a lifespan of over 50000 on/off cycles
completely solves the problems like stuck reed, rusted contact points, and
automatic shutdown conventional mechanical switches often have.The internal
capacitor module saves space and makes the wiring simple and neat.

Programming/Upgrading/Data
Reading Wirelessly

With Hobbywing’s “WiFi Express” module and iPhone or an Android phone (with the HOBBYWING WiFi Link
software installed), the user can remotely program parameters, upgrade firmware and
check relevant data of the ESC without leaving the control stand.
Adjustable Throttle & Brake PWM Frequencies

Independent and adjustable throttle & brake PWM frequencies guarantee precise and accurate
throttle and brake control for all classes of competitions (esp. the Stock class).
Separate Programming/Fan Port

The separate PRG/FAN port on the ESC can power an external fan to maximize cooling performance
or connect the ESC to a LCD program box or WiFi module for ESC programming.
Innovative Data-logging Function

This ESC features the data-logging function which can record the maximum ESC/motor
temperature, RPM and etc. in real time and allows users to check those
data via a LCD program box or WiFi module after each use.
